RedNet HD32R

Code: 3071

32x32 Pro Tools | HD I/O With Dual PSUs

Pre-Order Usually available within about 1 week from order

years

RedNet HD32R is a 1U, Pro Tools | HD™ interface for any Dante™ audio-over-IP network, providing up to 32x32 channels of I/O (16x16 at 192kHz) Featuring network and power supply redundancy, RedNet HD32R is the ideal choice for integrating your Pro Tools HD system into a Dante networked I/O environment in many critical-path applications, whether in Post Production, Broadcast, Live Sound or the Recording Studio.

A pair of DigiLink mini connectors allows RedNet HD32R to connect directly to any Pro Tools | HD system whether it's Native, HDX or even a legacy TDM system. Multiple RedNet HD32R units can be on the same Pro Tools system up to the maximum I/O channel count of Pro Tools, and Loop Sync I/O allows seamless integration with other Pro Tools interfaces such as HD I/O and Sync HD I/O.





32x32 Pro Tools | HD I/O for Dante audio-over-IP networks at up to 96kHz (16x16 at 192kHz).

Primary and Expansion DigiLink mini connections.

Up to 24-bit, 192kHz sampling rates.

AES67 compliant.

Dual power supplies and network connections with full power and network redundancy including locking connectors for maximum reliability.

Word Clock and Loop Sync I/O for increased flexibility and integration with other Pro Tools | HD hardware.

Comprehensive remote control and remote signal metering through RedNet Control.

Brainworx bx_console Focusrite – exclusive plug-in that faithfully captures the sound, feel and styling of the original Focusrite ISA 110 Equaliser and ISA 130 Dynamics Modules.





    DIGITAL PERFORMANCE:

    • Supported Sample Rates: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz (-4 / -0.1 / 0.1 / 4.167) at 24 bit
    • Clock Sources: Internal, Word Clock, Loop Sync (master or slave) or from Dante Network Master
    • External Word Clock Range: Nominal sample rate ±7.5
    • Channel Count: 32x32 at up to 96kHz sampling rate, 16x16 at 176.4 and 192kHz


    REAR PANEL CONNECTIVITY:

    • Primary Port: 1 x Mini DigiLink
    • Expansion Port: 1 x Mini DigiLink
    • Word Clock Input: 1 x BNC 75O port (switchable termination)
    • Word Clock Output: 1 x BNC 75O port
    • PSU: 2 x IEC Inputs with retaining clips
    • Network: 2 x etherCON NE8FBH-S, also compatible with standard RJ45 connectors


    FRONT PANEL INDICATORS:

    • Primary PSU (A): Green LED. Illuminates when an AC input is applied and all DC outputs are present
    • Primary PSU (B): Green LED. Illuminates when an AC input is applied and all DC outputs are present
    • Primary Network: Green LED. Indicates that a network connection is present on primary port when in redundant mode.
    • Secondary Network: Green LED. Indicates that a network connection is present on secondary port when in redundant mode.
    • Network Locked: Green LED. When unit is network slave, shows valid network lock. When unit is network master.
    • Sample Rate: Orange LED for each: 44.1 kHz, 48 kHz, x2, x4
    • Pull Up/Down: Orange LED. Indicates unit is set to operate on a Dante pull up/down domain
    • Signal Indicators: 16 Green LEDs, 8 input/8 output indicators. Illuminate @ -126dBFS
    • Clock Source: Orange LED for each: Internal, Word Clock, Loop Sync and DAW Master


    NETWORK MODES

    • Redundant: Allows unit to connect two independent networks
    • Switched: Connects both ports to integrated network switch allowing daisy-chaining of device


    DIMENSIONS:

    • Height: 44.5mm
    • Width: 482.6mm
    • Depth: 263mm


    WEIGHT:

    • Weight: 3.9kg


    POWER:

    • Power PSU: 2 x Internal, 100-240V, 50/60Hz, consumption 30VA


    HEAT PERFORMANCE:

    • Operating Temperature: Operates at up to an ambient temperature of 50 degrees Celcius
