PDM-T804 Stage Mixer

Code: 6770

Stage Mixer 8-Channel DSP/MP3

Price: €388.00
Price: €388.00
BUY Online: €358.00
BUY Online: €358.00
You Save €30
You Save €30
including 19% VAT Excluding VAT (For shipments to Non EU countries, or intra community upon VIES Validation) price, to be calculated during checkout
Get it with Free Delivery within 24 hours, at your closest Akis Express Collection point!
Add to Cart

In Stock

years

The PDM-T series is a series of stage mixers equipped with a 32-bit DSP effect processor, stereo 7-band graphic equalizer, BT streaming capability and USB input/output for easy connection to the computer for music recording, etc. It’s also possible to use the one click recording function for easy MP3 recordings on a USB stick. Each channel has its own gain control with treble, mid and bass controls. The microphone preamps offer selectable 48V phantom power on all microphone channels. The PDM-T mixers are designed to provide multi-channel mixing capabilities for bands, musicians, sound engineers, conferences, studio recording and a variety of other live stage applications.

    • 8-Channel multipurpose audio mixer
    • MP3 recording/playing via full-duplex USB port (one click recording)
    • BT receiver for audio streaming
    • +48V phantom power
    • Stereo 7-band graphic equalizer
    • 380 DSP multi effects with 4 memories
    • USB to PC for record and play music (USB interface)
    • 8x Microphone-/line input (Combi XLR/Jack)
    • High, Mid and Low control for each channel
    • Adjustable Pan, aux return input and FX send output
    • Adjustable headphone output
    • Stereo balanced main outputs (XLR/6.3mm Jack)
    • MUTE, PFL (Pre-fader listening), L/R, G1/G2 control on each channel
    • LED VU meter and Peak LEDs
  • Playback options: BT streaming, USB
  • Input Connections: 6.3mm Jack, RCA, USB, XLR (3-pin)
  • Output connections: 6.3mm Jack, RCA, USB, XLR (3-pin)
  • Presets: 380
  • DSP Resolution: 32-bit
  • Frequency response: 20Hz - 20.000Hz
  • THD: <0,5%
  • Equalizer: 7-Bands
  • Equalizer Low: 80Hz +15dB
  • Equalizer High: 12KHz +15dB
  • Power supply: 100-240VAC 50/60Hz
  • Dimensions (L x W x H): 377 x 455 x 120mm
  • Weight: 4.85kg
